Install SAP B1 WebClient Plugin in VS Code 2022
✅ Professional Guide: Install SAP
B1 WebClient Plugin via VSIX in Visual Studio Code
🖥️ Prerequisites:
- Visual
Studio Code installed on your system.
- SAP
Business One SDK installed.
- .VSIX
file located at:
C:\Program Files (x86)\SAP\SAP Business
One\SDK\Tool\WebClientVSCodePlugins
🔧 Step-by-Step
Instructions
Step 1: Open Visual Studio Code
- Launch
Visual Studio Code from the desktop or Start Menu.
Step 2: Open the Extensions Marketplace
- On the
left-hand sidebar, click the Extensions icon (or press Ctrl + Shift
+ X).
- This
opens the Extensions panel, where all available and installed
extensions are managed.
Step 3: Click on the Three-Dot Menu
- In the
top-right corner of the Extensions panel, click the ellipsis (⋮)
button to open the context menu.
Step 4: Select “Install from VSIX...”
- From
the dropdown options, click on
Install from VSIX...
Step 5: Browse to the SAP B1 VSIX File Location
- A file
selection dialog will appear.
- Navigate
to the folder:
C:\Program Files (x86)\SAP\SAP Business
One\SDK\Tool\WebClientVSCodePlugins
Step 6: Select the VSIX File
- In
this folder, locate the file:
sap-businessone-webclient-extension-tool-1.0.1.vsix
- Select
the file and click Open.
Step 7: Complete the Installation
- Visual
Studio Code will begin installing the extension.
- Once
complete, a success message will appear.
Step 8: Verify Installation
- After
successful installation, the extension will appear in the list as:
SAP Business One WebClient Extension Tool
- You
may also see the section titled:
SAP WebClient Plugins
✅ What You Can Do After
Installation:
With the extension installed, you can:
- Create
new UI API apps and URL Mashup extensions
- Debug
and preview SAP Web Client plugins
- Package
plugins for deployment
- Use
commands like:
- SAP
Business One WebClient: Create New Project
- SAP
Business One WebClient: Preview Extension
📌 Summary
Step |
Action |
1 |
Open Visual Studio Code |
2 |
Go to Extensions (Ctrl + Shift + X) |
3 |
Click on ⋮ (three-dot menu) |
4 |
Choose Install from VSIX... |
5 |
Navigate to: C:\Program Files (x86)\SAP\SAP Business
One\SDK\Tool\WebClientVSCodePlugins |
6 |
Select: sap-businessone-webclient-extension-tool-1.0.1.vsix |
7 |
Click Open and wait for installation |
8 |
Extension appears as SAP Business One WebClient
Extension Tool |
⚠️
Important Note:
This process is for Visual Studio Code, not Visual Studio 2022 IDE. The
SAP WebClient Plugin Tool is only supported in VS Code.
