Tips to Install SAPB1 WebClient Plugin in VS Code 2022

How to Install SAP Business One Web Client Plugin in Visual Studio Code (VS Code)

Installing the SAP Web Client plugin for Visual Studio Code allows developers to efficiently work with SAP Business One UI components, including Fiori tiles and UI APIs. If you are working in a Windows RDP (Remote Desktop Protocol) server environment, follow this step-by-step guide to install and verify the plugin properly for any user.


🔧 Prerequisites

  • Visual Studio Code installed (preferably system-wide).
  • Administrative rights to install software.
  • Access to SAP Business One SDK tools.

🚀 Step-by-Step Installation Guide

Step 1: Launch Visual Studio Code and Install SAP Fiori Tools Extension

  1. Open Visual Studio Code.
  2. Press Ctrl + Shift + X to open the Extensions panel.
  3. Search for “SAP Fiori tools - Extension Pack”.
  4. Click Install to add it to your VS Code environment.


This extension provides the required base to work with SAP UI5 and Fiori elements.


Step 2: Choose the User Profile for Installation

Determine which Windows user account should have access to the plugin (e.g., Brajesh.pawar). This is important because VS Code extensions are installed per user, not system-wide by default.


Step 3: Grant Administrative Rights and Run the Installer

  1. Log in using the intended user account (e.g., sanjay.kumar) via Remote Desktop.
  2. Ensure this user has Administrator privileges temporarily.
    • Open Control Panel > User Accounts > Manage another account > Change account type.
    • Set to Administrator if not already.
  3. Navigate to the following location:

C:\Program Files (x86)\SAP\SAP Business One\SDK\Tool\WebClientVSCodePlugins

  1. Locate the file install.bat.
  2. Double-click install.bat to run the installation as the current user.

🔄 Running the installer as another user or with Run as Administrator (UAC prompt) won’t install the plugin correctly for the active user profile.


🛠️ If install.bat Does Not Work: Run the PowerShell Script




If the standard install.bat file does not work or opens multiple CMD windows, follow this alternative approach:

  1. Navigate to:

C:\Program Files (x86)\SAP\SAP Business One\SDK\Tool\WebClientVSCodePlugins\script\

  1. Locate the file: install.batch
  2. Right-click and run it using PowerShell, but make sure you're logged in as a user with Administrator rights.
    • You can also open PowerShell manually and run the script using:
      First you need to run this script with the click on right click





powershell

.\install.batch

🛡️ This method is necessary when the regular installer fails or triggers a recursive CMD loop.




Step 4: Verify Installation in Visual Studio Code

  1. After installation, reopen Visual Studio Code.
  2. Press Ctrl + Shift + P to open the Command Palette.
  3. Search for and select:
    Template Wizard: Open Template Wizard
  4. If installation was successful, you will see:
  • SAP Business One Web Client Templates
  • Tile and UI API Options


🎉 If you see these, the plugin has been successfully installed and is ready to use.


📌 Notes & Best Practices

  • Always install the plugin as the same user who will use it.
  • Remove Administrator rights after installation (if required for policy).
  • Avoid using broken or recursive install.bat files from older SDK builds. Use .vsix if available.
  • Use the Fiori tools extension as a foundation before WebClient plugin installation.

🧩 Troubleshooting Tips

Issue

Solution

CMD windows open in a loop

Don’t run faulty install.bat. Use the install.batch PowerShell script instead

Plugin not visible after install

Make sure installation was done using the correct user

Template Wizard not showing SAP options

Reinstall plugin or check if Fiori Tools pack is installed


Conclusion

Installing the SAP Business One Web Client plugin for Visual Studio Code is a simple but user-specific process. By following the above steps, you ensure the correct user environment is configured with the necessary tools to work on SAP UI-based development projects using VS Code.
